AILI Battery Monitor 5-120V +/- 400A Voltage Current Remaining Capacity No need Shunt

This Battery Monitor is designed to monitor performance most kind of battery systems with capacities of up to 999 Amp hours. Read your battery bank like a fuel gauge Combines many functions in one, these information leads to more efficient use of the battery, which can enhance battery life and reduce the risk of failure. Top row display Voltage (V), bottom row display below reading: Charge and discharge current (A) Charge and discharge capacity (AH) The remaining battery capacity, State of Charge (%) Configurable different display mode, fixed or cycle display: A, AH, -AH, PC (State of charge), A-PC. Charging status indicator, scrolling text animation when charging current higher than 0.5 amps. Come with a Through-hole Current transformer, it doesn't require shunt. The current sensor can be placed on the Positive or Negative side of power. Reverse polarity protection. Doesn't require isolated power, self-powered 5-120V. Nondestructive installation, it is very easy to install. Technical Specification Power Supply 5~120Vdc (Self-powered) Voltage Range 5~120V Current Range -400 ~ +400 A Capacity Range 0-999Ah Resolution 0.1V, 1A, 0.1AH Display Type Dual Display Red & Blue LED Sensor hole dimeter 20mm Dimensions 48mm*29*23 Panel Cut-out 45.5mm*25.5mm1X 2 meters long cable

• Through-hole design: No wiring difficulty. Measure positive or negative current. No current direction limitation
• Electrically isolated from high voltage power source which eliminates risk to delicate monitoring equipment and also minimizes safety concerns
• Display Voltage or (+ -)Current. Voltage Range: 5V-120V. Current range: 0-400A
• Large wire capability: Diameter of the hole through sensor is 3/4 inch(19 mm)
• Loop through sensor multiple times to strengthen signal. For example, if your current signal is only 0.2 Amps, you could loop the wire through the sensor 10 times and the signal would by 10X stronger and would appear as 2.0 Amps
